Product Specifications
Power | |
AC Input Range | 100/240 VAC, 50/60 Hz, 1.0/1.5 A, Class 2 115 V, 400 Hz, 1.5 A (nominal for aircraft use) |
DC Output | 24 VDC, 3.75 A |
Typical Power Consumption | 53 W (57 VA) |
Peak Power Consumption | 104 W (108 VA) |
Environmental Conditions | |
Operating Temperature | 5° C to 35° C |
Operating Humidity | 10 to 95% RH (non-condensing) |
Operating Altitude | Sea level to 2,591 m; Air pressure 1013 hPa to 738 hPa |
Storage & Transport Temperature | -20° C to 60° C |
Storage & Transport Humidity | 5 to 95% RH (non-condensing) |
Physical | |
Ingress Protection | IP22 |
Dimensions | 11.6 cm H × 25.5 cm W × 15 cm |
Air Outlet | 22 mm |
Weight | 1.34 kg |
Water Capacity | Max 380 ml |
Performance | |
Sound Pressure Level | Max 35 dBA ± 2 dBA |
Operating Modes & Pressure Range | APAP, CPAP: 4 to 20 cm H₂O |
Supplemental Oxygen | Max 4 L/min |
This table lists product specifications and features.
FAQs
Where should I place the device for use?
Place the device on a firm, flat surface within easy reach, and ideally at a level slightly lower than your sleeping position.
Can I put the system in checked baggage when travelling?
No. The carrying case is designed for carry-on luggage and may not protect the system in checked baggage.
What should I do if I’m travelling with the humidifier?
Always empty the water tank before travelling. Do not transport the device with water inside.
How can I make the security process easier when travelling with the system?
The device is safe to be transported and used in flight. There is a note on the bottom of the device stating that it is medical equipment and suitable for airline use. Bringing the manual may also help security personnel understand the Stellar 100 V device. Click ResMed AirStart 10 flight travel compliance letter (PDF) to download the manufacturer's flight safety declaration.
What about power compatibility when travelling internationally?
The AirStart 10 supports a wide voltage range, but you may need a different power cord or plug adaptor depending on the country.
